PolyshieldTM is tough under the sun

PolyshieldTM is a high quality woven/coated HDPE reinforced fabric designed as a general purpose cover for agricultural, horticultural, emergency and industrial purposes. It is suitable for hay stack and cotton module covers, stationary machinery covers and disaster protection. Also used in the RV and camping industries for tent flooring and protection covers. It is made from virgin resins, and uses only the best UV stabilizers from BASF to ensure that the fabric retains its flexibility and strength under the harsh Australian sun.

PolyshieldTM comes with a 3 year warranty* covering premature breakdown as a result of exposure to the suns UV rays.

Quality UV additives are applied to the tapes that are woven into the reinforced scrim, and to the hot melt extruded coatings.

PolyshieldTM is available in 81” wide x 55 yard rolls (stocking) and 1,094 yard rolls (special order).

Polyshield‘sTM color range includes Green, Yellow, Blue, Beige, White, White/Silver and Green/Silver.

Welding and joining

PolyshieldTM is easily joined with a commercial sewing machine and has excellent weldability. We recommend that if you are using a tape welder, that you use compatible welding tapes split from rolls of Polyshield.

POLYSHIELD
Base FabricHDPE
Weight7.4 oz/sq. yd (250gsm) +/- 10%
Roll Sizes81” wide x 55 yard rolls (stocking)

1,094 yard rolls (special order)
UV Stabilization3 Year UV Breakdown Warranty**
Colors:Green, Yellow, Blue, Beige, White

White/Silver, Green/Silver
Lamination2 x 55 microns - LDPE
Tolerance10% in weight and properties
Construction of base fabric 12 x 12 - 1500 D - HDPE
WARPWEFT
Breaking force/50mm:lbs15911353
Breaking extension:%20.820.1
Tear resistance (Mean):lbs5756
Bursting force (Mean):lbs/in432432
Hydrostatic Pressure

AS 2001.2.17-1988
150kPa
Coating Thickness5.5 micron both sides

POLYSHIELDTM (“fabric”) is a high quality reinforced HDPE fabric suitable for disaster and storm tarps, haystack covers, stationary equipment covers and tent flooring.

Limited Warranty

Polyfab USA LLC (“Polyfab”) warrants to the initial purchaser of the fabric that the fabric will not suffer from abnormal deterioration from ultra violet exposure for a period of 3 years from the date of installation. The term abnormal deterioration means deterioration exceeding 20% of the fabric’s original strength for each year over the 3-year warranty period, and does not include normal wear and tear. If the fabric does suffer from abnormal deterioration during the 3-year warranty period, Polyfab will, at its option, either replace the fabric or supply equivalent fabric, or pay to the initial purchaser the cost of replacing the fabric or of acquiring equivalent fabric on the following pro-rata basis:

1st year 100% of the original fabric purchase price

2nd year 70% of the original fabric purchase price

3rd year 40% of the original fabric purchase price

POLYFAB UNDERTAKES NO RESPONSIBILITY FOR THE QUALITY OF THE FABRIC EXCEPT AS OTHERWISE PROVIDED HEREIN. THERE IS NO IMPLIED WARRANTY THAT THE FABRIC SHALL BE MERCHANTABLE. POLYFAB ASSUMES NO RESPONSIBILITY THAT THE FABRIC WILL BE FIT FOR ANY PARTICULAR PURPOSE FOR WHICH YOU MAY BE BUYING THE FABRIC, EXCEPT AS OTHERWISE PROVIDED HEREIN. THERE IS NO IMPLIED WARRANTY THAT THE FABRIC SHALL BE FIT FOR ANY PARTICULAR PURPOSE. YOU ACKNOWLEDGE THAT YOU ARE NOT RELYING ON POLYFAB’S SKILL OR JUDGMENT TO SELECT OR FURNISH THE FABRIC SUITABLE FOR ANY PARTICULAR PURPOSE AND THAT THERE IS NO WARRANTY WHICH EXTENDS BEYOND THAT PROVIDED HEREIN.

Exclusions and Product Disclaimers

This limited warranty does not cover, and Polyfab is not liable for, abnormal deterioration of fabric occurringdue to any of the following circumstances:

  • Exposure to pollution, chemicals, solvents, cleaning agents or other substances that are harmfulto the performance of the fabric.
  • Faulty installation of the fabric or faulty design or manufacture of any structure to which thefabric is attached.
  • Improper storing, handling, bracing, use of the fabric or use contrary to the specifications for the fabric.
  • Color fading. Color fading is normal over time. Fabric colors containing red or yellow pigments have a tendency to fade more than others. Color Fading is not abnormal deterioration or a loss of strength/breakdown and is not covered by this warranty.
  • Minor color variation from fabric samples.
  • Minor visual imperfection due to the manufacturing processes.
  • The negligent act or omission of any person.
  • Misuse, neglect or abuse of the fabric.
  • During installation, the fabric should not be subject to “pre-stressed” loading in excess of 20%.
  • Wind flap and storm damages are major causes of abnormal deterioration and premature breakdown in any quality outdoor fabric. It is therefore critical that the fabric be installed firm and tight and maintained in a firm condition. Fabric that is allowed to flap and cause rubbing and abrasion as a result of excessive and continual wind flap or storm damage on structural poles and support wires is mechanical breakdown and not covered by this warranty.
  • The fabric should be supported by using appropriate strength poles and footings as determined by a professional structural engineer, and fabricated and installed by a qualified contractor in accordance with local building codes.
  • Technical testing information supplied by Polyfab is sourced from third-party testing authorities, and tolerances may vary by as much as 10%.

Limitation of Liability

Polyfab’s obligations and liabilities are expressly and exclusively limited to those set forth herein. EXCEPT AS OTHERWISE PROVIDED FOR HEREIN, POLYFAB SHALL NOT BE LIABLE FOR DIRECT, INDIRECT, INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES, INCLUDING LOSS OF PROFITS OR OTHER COMMERCIAL LOSSES, INCLUDING CLAIMS BASED ON NEGLIGENCE OR STRICT LIABILITY. IN THE EVENT POLYFAB IS FOUND TO BE LIABLE FOR ANY DAMAGE OR LOSS RELATED TO THE FABRIC, SUCH LIABILITY SHALL BE LIMITED TO THE ORIGINAL PURCHASE PRICE OF THE FABRIC.

Claims Procedure

All claims under this limited warranty must be made in writing, within 30 days from the date upon which the defect became known to the initial purchaser, to Polyfab USA LLC, 1601 N. Sepulveda Blvd. #392, Manhattan Beach, CA 90266. Claims must be supported by a sample of the defective fabric together with proof of purchase, including the date and location of fabric purchase, and photos of the finished installation.
